Batteries
Product Details
| Model | 73.6V | 76.8V |
| Basic Parameter | ||
| Rated Voltage | 73.6V | 76.8V |
| Voltage Range | 57.5-82.8V | 67.2-87.6V |
| Combination | 1P23S | 1P24S |
| Module | 1P23S | 1P24S |
| Rated Energy | 7.6kWh | 8kWh |
| Cell Type | LFP 3.2V/104Ah | LFP 3.2V/105Ah |
| Charge Mode | CC-CV | CC-CV |
| Continues Charge Current | 104A (max) | 125 (max) |
| Continues Discharge Current | 104A (max) | 105 (max) |
| Charge Temperature Range | 0-55°C | 0-55°C |
| Discharge Temperature Range | -20-60°C | -20-60°C |
| Communication Port | CAN2.0/RS485/RS232 | CAN2.0/RS485/RS232 |
| Battery Protection | Over Charge/Over Discharge/Over Temperature/Over Current/Short Circuit | Over Charge/Over Discharge/Over Temperature/Over Current/Short Circuit |
| Other Parameter | ||
| Size(WHT) | 780*320*200mm | 850*290*296mm |
| Weight | 68kg | 84kg |
| IP Circuit | IP55 | IP55 |
| Product Features | ||
| Electrical scheme | MOS | Relay scheme |
| Charging scheme | 25A (Slow charging machine) | Maximum support for 125A fast charging Compatible with 25A slow charging machine |
